Types Of Pipe Fittings By Connection Method

Stainless Steel Weld Fitting: pipe fittings connected to pipes by welding, including elbows, flanges, tees, reducers, caps, etc. Threaded pipe fittings: pipe fittings with threads, commonly used in water and gas pipes, small diameter water pipes, compressed air pipes and low-pressure steam pipes, etc.
Ferrule pipe fittings: a new type of quick pipe connector with good sealing performance and can be used repeatedly, suitable for pipeline systems of oil, gas and general corrosive media.
Clamp pipe fittings: used to tighten the connection between quick connectors, including clamps, quick connectors, silicone sealing gaskets, chuck blind plates, etc.
Socket pipe fittings: a high-pressure pipeline connection fitting formed by round steel or steel ingot die forging blanks and processed by lathes.
Curved elastic double-melt pipe fittings: pipe fittings with ports of the same size as the pipe to be connected, connected by hot-melt butt welding.
Adhesive pipe fittings: pipe fittings connected by solvent-based adhesives, such as PVC plastic pipes, etc.
Rubber ring connection type pipe fittings: composed of the pipe fitting body, sealing end cover and sealing rubber ring.
